Technical data
| Rated power input |
1.300 W |
| No-load speed |
0 – 900 / 3.000 rpm |
| Power output |
695 W |
| Weight without cable |
2,9 kg |
| Rated speed |
900 – 3.000 rpm |
| Torque (soft screwdriving applications) |
43,0 / 20,5 Nm |
| Rated torque |
7,8 / 2,6 Nm |
| Drill spindle connecting thread |
1/2" – 20 UNF |
| Chuck capacity |
1,5 – 13 mm |
| Impact rate at no-load speed |
0 – 15.300 / 51.000 bpm |
| Max. torque |
43,0 / 20,5 Nm |
| Drilling range |
|
| Drilling dia. in concrete |
22 / 13 mm |
| Drilling dia. in wood |
40 / 25 mm |
| Drilling dia. in steel |
16 / 10 mm |
| Drilling dia. in masonry |
24 / 16 mm |
Functions
- Multiple gears
- Forward/reverse operation
- Electronic
- Constant Electronic
- Power Control
- Auto-Lock
- Softgrip
- Overload clutch
Noise/vibration information
Measured values determined according to EN 60745.
Total vibration values (vector sum of three directions)
| Drilling in metal |
| Vibration emission value ah |
5,6 m/s² |
| Uncertainty K |
1,5 m/s² |
| Impact drilling in concrete |
| Vibration emission value ah |
14,6 m/s² |
| Uncertainty K |
1,8 m/s² |
| Screwdriving |
| Vibration emission value ah |
2,5 m/s² |
| Uncertainty K |
1,5 m/s² |
| Thread-cutting |
| Vibration emission value ah |
2,5 m/s² |
| Uncertainty K |
1,5 m/s² |
The A-rated noise level of the power tool is typically as follows: Sound pressure level 95 dB(A); Sound power level 106 dB(A). Uncertainty K= 3 dB.
