Technical data
| Rated power input |
701 W |
| No-load speed |
0 – 3.000 rpm |
| Power output |
351 W |
| Weight without cable |
1,9 kg |
| Drill spindle connecting thread |
1/2" – 20 UNF |
| Chuck capacity |
13 mm |
| Drilling range |
|
| Drilling dia. in concrete |
16 mm |
| Drilling dia. in wood |
30 mm |
| Drilling dia. in steel |
12 mm |
| Drilling dia. in masonry |
18 mm |
Functions
- Forward/reverse operation
- Electronic
- Softgrip
Noise/vibration information
Measured values determined according to EN 60745.
Total vibration values (vector sum of three directions)
| Drilling in metal |
| Vibration emission value ah |
2,7 m/s² |
| Uncertainty K |
1,5 m/s² |
| Impact drilling in concrete |
| Vibration emission value ah |
23,0 m/s² |
| Uncertainty K |
3,5 m/s² |
| Screwdriving |
| Vibration emission value ah |
2,5 m/s² |
| Uncertainty K |
1,5 m/s² |
The A-rated noise level of the power tool is typically as follows: Sound pressure level 98 dB(A); Sound power level 109 dB(A). Uncertainty K= 3 dB.
