Technical data
| Rated power input |
600 W |
| Impact energy |
0 – 3 J |
| Impact rate at rated speed |
0 – 4.260 bpm |
| Rated speed |
0 – 960 rpm |
| Battery voltage |
36 V |
| Weight incl. battery |
4,5 kg |
| Length |
396,0 mm |
| Width |
107,0 mm |
| Height |
221,0 mm |
| Toolholder |
SDS-plus |
| Drilling range |
|
| Drilling diameter in concrete with hammer drill bits |
4 – 26 mm |
| Optimum range of applications in concrete with hammer drill bits |
8 – 16 mm |
| Max. drilling diameter in steel |
13 mm |
| Max. drilling diameter in wood |
30 mm |
Functions
- Forward/reverse operation
- Overload clutch
- Bosch SDS System
Noise/vibration information
Measured values determined according to EN 60745.
Total vibration values (vector sum of three directions)
| Hammer drilling in concrete |
| Vibration emission value ah |
20,0 m/s² |
| Uncertainty K |
1,5 m/s² |
The A-rated noise level of the power tool is typically as follows: Sound pressure level 91 dB(A); Sound power level 102 dB(A). Uncertainty K= 3 dB.
