Technical data
Rated power input |
430 W |
Impact energy |
0 – 1,8 J |
Impact rate at rated speed |
0 – 4.850 bpm |
Rated speed |
0 – 1.500 rpm |
Battery voltage |
36 V |
Battery capacity |
1,3 Ah |
Weight incl. battery |
2,9 kg |
Length |
297,0 mm |
Width |
83,0 mm |
Height |
207,0 mm |
Toolholder |
SDS-plus |
Drilling range |
|
Drilling diameter in concrete with hammer drill bits |
4 – 18 mm |
Optimum range of applications in concrete with hammer drill bits |
4 – 10 mm |
Max. drilling diameter in steel |
13 mm |
Max. drilling diameter in wood |
30 mm |
Functions
- Forward/reverse operation
- Electronic
- Overload clutch
- Bosch SDS System
Noise/vibration information
Measured values determined according to EN 60745.
Total vibration values (vector sum of three directions)
Hammer drilling in concrete |
Vibration emission value ah |
10,0 m/s² |
Uncertainty K |
1,5 m/s² |
The A-rated noise level of the power tool is typically as follows: Sound pressure level 91 dB(A); Sound power level 102 dB(A). Uncertainty K= 3 dB.
