Technical data
| Torque, max. (hard screwdriving applications) |
45 Nm |
| Torque, max. (soft screwdriving applications) |
19 Nm |
| No-load speed (1st gear/2nd gear) |
0 – 400 / 1.400 rpm |
| Max. impact rate |
21.000 bpm |
| Chuck jaw width, min./max. |
1,5 / 10 mm |
| Drill spindle thread |
1/2" |
| Battery voltage |
18 V |
| Weight incl. battery |
1,5 kg |
| Torque settings |
15+1 |
| Drilling diameter |
|
| Max. drilling diameter in wood |
29 mm |
| Max. drilling diameter in steel |
10 mm |
| Max. drilling diameter in masonry |
10 mm |
| Screw diameter |
|
| Max. screw diameter |
8 mm |
Functions
- Multiple gears
- Impact drilling
- Forward/reverse operation
- Electronic
- Auto-Lock
- Softgrip
- Light
Noise/vibration information
Measured values determined according to EN 60745.
Total vibration values (vector sum of three directions)
| Drilling in metal |
| Vibration emission value ah |
3,0 m/s² |
| Uncertainty K |
1,5 m/s² |
| Impact drilling in masonry |
| Vibration emission value ah |
13,0 m/s² |
| Uncertainty K |
1,5 m/s² |
| Screwdriving |
| Vibration emission value ah |
2,5 m/s² |
| Uncertainty K |
1,5 m/s² |
The A-rated noise level of the power tool is typically as follows: Sound pressure level 84 dB(A); Sound power level 95 dB(A). Uncertainty K= 3 dB.
