| Includes templates for locks having the following dimensions: |
|
| Face-plate Dimensions |
|
| Imperial (Metric) |
Template |
| 7/8"x6" (22.2x156 mm) |
1 |
| 7/8"x6 " (22.5x152.5 mm) |
2 |
| 1"x4 3/4" (25.4x121 mm) |
3 |
| 1"x5"(25.4x128 mm) |
4 |
| 1"x5 1/4"(25.4x133.5 mm) |
5 |
| 1"x5 3/4"(25.4x145 mm) |
6 |
| 1"x6"(25.4x153 mm) |
7 |
| 1"x6"(25.4x156.5 mm) |
8 |
| 1"x6 1/2"(25.4x165.5 mm) |
9 |
| 1"x7"(25.4x177 mm) |
10 |
| 1"x2 1/4"(25x57.5 mm) |
11 UPPER |
| 1"x2 1/4"(26x56.5 mm) |
11 LOWER |
| Mortise Dimensions |
|
| Imperial (Metric) |
Template |
| 5/8"x2 3/4" 16x72 mm |
A |
| 5/8"x4 1/4" 16x107 mm |
B |
| 3/4"x3" 19x78 mm |
C |
| 3/4"x4 1/4" 19x109 mm |
D |
|
